Airbus ASERIS™ Suite

The ASERIS™ electromagnetic simulation suite


In partnership with Airbus since 2006, IMACS is co-developing the ASERIS™ Software Suite, an essential link in the aircraft design chain (Design, certification and maintenance).

IMACS is the exclusive distributor worldwide for the ASERIS™ suite.

With respect to other commercial software products dealing with electromagnetic phenomena, ASERIS™ main strengths are :
  • a commitment to solve real life problems issued from complex industrial applications,
  • high reliability,
  • very high performance (from desktop PCs to massively parallel supercomputers).
"Slogan 1!"

Slogan 2
A variety of solvers

The ASERIS™ suite for computational electromagnetics was initially developed to serve the needs of the different Airbus Business Units for design, certification and maintenance. ASERIS™ is being codeveloped in partnership with the company IMACS which is responsible for its maintenance and distribution.

A variety of solvers and software components have been developed to adapt to each different situations:
  • ASERIS-BE: based on Boundary Element Method (BEM) in the frequency domain.
    It implements fast solvers such as multi-level Fast Multipole Method (FMM) and H-matrix method. Main applications: radar cross section (RCS), antenna design, antenna siting, EMC, lightning indirect effects (LIE), High intensity radiated fields (HIRF).

  • ASERIS-FD: based on Finite Difference Time Domain method (FDTD).
    Initially developed for RCS analysis, it is mainly used for EMC, Lightning and HIRF

  • ASERIS-NET: Transmission Line Matrix method (TLM) in the frequency domain.
    It is used for network analysis and EMC

  • ASERIS-HF: based on Geometric Theory of Diffraction method (GTD / UTD).
    Mainly used for high frequency propagation, antenna siting, RCS

  • ZEBRA:CAD/CAE graphical user interface for ASERIS-FD, ASERIS-FD - ASERIS-NET « 3DNET » coupling and ASERIS-BE
    Antenna sitting applications (3D XML import, CAD simplification, meshing operations.)
They are using ASERIS™ Software Suite

In addition to Airbus Operations, Airbus Helicopters and Airbus Defense and Space, ASERIS™ suite is already used by different companies as

Benefit from Airbus ASERIS™ proven Suite for Electomagnetics
As exclusive distributor worldwide for the ASERIS™ suite, IMACS provides
  • distribution,
  • training,
  • maintenance,
  • support,
  • and... software development to adapt to your specific needs.
For more information or for a demo
